Burnett & Hillman Hydraulic Adaptors
All text and product images are the intellectual property and copyright of Pipestock Limited
Key Features / Tech Specs:
- Manufacturer: Burnett & Hillman
- Hydraulic adaptors
- Manufactured to BS EN 10277
- Material: Steel
Useful Info:
Burnett and Hillman are a UK based manufacturer of high-quality steel hydraulic fittings. With over 50 years of experience, they are one of the largest manufacturers of hydraulic adaptors with an extensive range of BSP, JIC and ORFS fittings all built to BS EN 10277.
BSP Hydraulic Adaptors | ORFS Hydraulic Adaptors |
Nut - Nominal Size | Tightening Torque | Nut - Nominal Size | Tightening Torque |
BSP Size | NM | Lbsf/ft | SAE Dash | Thread | BSP Size | NM | Lbsf/ft |
1/8 | 17 | 12 | -4 | 9/16-18 | 1/4 | 24 | 18 |
1/4 | 34 | 25 | -6 | 11/16-16 | 3/8 | 33 | 24 |
3/8 | 47 | 35 | -8 | 13/16-16 | 1/2 | 44 | 35 |
1/2 | 102 | 75 | -10 | 1-14 | 5/8 | 58 | 43 |
5/8 | 122 | 90 | -12 | 1-3/16-12 | 3/4 | 84 | 62 |
3/4 | 149 | 110 | -16 | 1-7/16-12 | 1 | 115 | 85 |
1 | 203 | 150 | -20 | 1-11/16-12 | 1 1/4 | 189 | 140 |
1 1/4 | 305 | 225 | -24 | 2-12 | 1 1/2 | 244 | 180 |
1 1/2 | 305 | 225 | - | - | - | - | - |
2 | 400 | 296 | - | - | - | - | - |
Nut - Nominal Size | Tightening Torque | Nut - Nominal Size | Tightening Torque |
Metric | NM | Lbsf/ft | JIC & SAE Connections | NM | Lbsf/ft |
M10 | 18 | 13 | 5/16-24 | 10 | 7 |
M12 | 20 | 15 | 3/8-24 | 10 | 7 |
M14 | 25 | 19 | 7/16-20 | 14 | 10 |
M16 | 45 | 33 | 1/2-20 | 20 | 15 |
M18 | 50 | 37 | 9/16-18 | 22 | 20 |
M20 | 70 | 52 | 5/8-18 | 27 | 20 |
M22 | 75 | 55 | 3/4-16 | 48 | 35 |
M26 | 110 | 81 | 7/8-14 | 81 | 60 |
M27 |
130 |
96 | 1 1/16-12 | 108 | 79 |
M33 | 220 | 162 | 1 3/16-12 | 136 | 100 |
M42 | 230 | 170 | 1 5/16-12 | 148 | 108 |
M48 | 350 | 258 | 1 5/8-12 | 173 | 127 |
- | - | - | 1 7/8-12 | 216 | 158 |
- | - | - | 2 1/2-12 | 334 | 245 |
If you require any further information then don’t hesitate to ring us here at Pipestock on 0845 634 1053. We’re always happy to help!
