Steel Tube

Steel Tube

Click on the image to activate zoom.

All text and product images are the intellectual property and copyright of Pipestock Limited

Key Features / Tech Specs & Dimensions:

  • Material: steel (chromium-6 free plated)
  • Manufactured to DIN 2391/C ST37.4
  • Maximum rated temperature: 120°C
  • Available up to 989 bar (size dependent)
  • Sizes 4mm to 50mm available
Product Code Outer Diameter (mm) Wall Thickness (mm) Max. Operating Pressure (bar) Length (m)
363827 4 1 624 3
363828 6 1 365 3
363829 6 1.5 624 3
363830 6 2 989 3
363831 8 2 259 3
363832 8 1.5 423 3
363833 8 2 624 3
363834 10 1 201 3
363882 10 1 201 6
363835 10 1.5 321 3
363883 10 1.5 321 6
363836 10 2 460 3
363884 10 2 460 6
363837 12 1 164 3
363885 12 1 164 6
363838 12 1.5 259 3
363886 12 1.5 259 6
363839 12 2 365 3
363887 12 2 365 6
363840 14 1.5 217 3
3638888 14 1.5 217 6
363841 14 2 303 3
363889 14 2 303 6
363842 15 1.5 201 3
363890 15 1.5 201 6
363843 15 2 279 3
363891 15 2 279 6
363844 16 1.5 187 3
363892 16 1.5 187 6
363845 16 2 259 3
363893 16 2 259 6
363846 16 2.5 337 3
363894 16 2.5 337 6
363847 16 3 423 3
363895 16 3 423 6
363848 18 1.5 164 3
363896 18 1.5 164 6
363849 18 2 226 3
363897 18 2 226 6
363850 18 2.5 300 3
363898 18 2.5 300 6
363851 20 2 201 3
363899 20 2 201 6
363852 20 2.5 259 3
363900 20 2.5 259 6
363853 20 3 321 3
363901 20 3 321 6
363854 20 3.5 388 3
363902 20 3.5 388 6
363855 20 4 460 3
363903 20 4 460 6
363856 22 1.5 132 3
363904 22 1.5 132 6
363857 22 2 181 3
363905 22 2 181 6
363858 22 2.5 232 3
363906 22 2.5 232 6
363859 25 1.5 115 3
363907 25 1.5 115 6
363860 25 2 157 3
363908 25 2 157 6
363861 25 2.5 201 3
363909 25 2.5 201 6
363862 25 3 247 3
363910 25 3 247 6
363863 25 4 347 3
363911 25 4 347 6
363864 28 1.5 102 3
363912 28 1.5 102 6
363865 28 2 139 3
363913 28 2 139 6
363866 28 2.5 177 3
363914 28 2.5 177 6
363867 28 3 217 3
363915 28 3 217 6
363868 30 2.5 164 3
363916 30 2.5 164 6
363869 30 3 201 3
363917 30 3 201 6
363870 30 4 279 3
363918 30 4 279 6
363871 35 2 109 3
363919 35 2 109 6
363872 35 2.5 139 3
363920 35 2.5 139 6
363873 35 3 169 3
363921 35 3 169 6
363874 35 5 303 3
363922 35 5 303 6
363875 38 3 155 3
363923 38 3 155 6
363876 38 4 213 3
363924 38 4 213 6
363877 42 3 139 3
363925 42 3 139 6
363878 42 4 190 3
363926 42 4 190 6
363879 50 3 115 3
363927 50 3 115 6
363879 50 5 201 3
363928 50 5 201 6
363880 50 6 247 3
363929 50 6 247 6



Technical Info:

These precision seamless steel pipes are coated with a chromium-6 free plating for corrosion resistance, and the maximum working pressures have been tested and rated in accordance with DIN 2413 (load case 1), for use in hydraulic applications.

Our hydraulic steel pipe has been tested for primarily static load conditions, meaning a constant load of force is exerted.



If you require any further information then don’t hesitate to ring us here at Pipestock on 0845 634 1053. We’re always happy to help!

More Info Close
Code
Product Name
List Price
You Pay
You Save
Quantity
Steel Tube Hydraulic 3m x 1mm x 4mm
Code
363827
Product Name
Steel Tube Hydraulic 3m x 1mm x 4mm
List Price
£27.40
You Pay
£18.36
You Save
33%
Qty
Steel Tube Hydraulic 3m x 1mm x 6mm
Code
363828
Product Name
Steel Tube Hydraulic 3m x 1mm x 6mm
List Price
£28.60
You Pay
£19.16
You Save
33%
Qty
Steel Tube Hydraulic 3m x 1.5mm x 6mm
Code
363829
Product Name
Steel Tube Hydraulic 3m x 1.5mm x 6mm
List Price
£31.80
You Pay
£21.31
You Save
33%
Qty
Steel Tube Hydraulic 3m x 2mm x 6mm
Code
363830
Product Name
Steel Tube Hydraulic 3m x 2mm x 6mm
List Price
£48.05
You Pay
£32.19
You Save
33%
Qty
Steel Tube Hydraulic 3m x 1mm x 8mm
Code
363831
Product Name
Steel Tube Hydraulic 3m x 1mm x 8mm
List Price
£38.10
You Pay
£25.53
You Save
33%
Qty
Steel Tube Hydraulic 3m x 1.5mm x 8mm
Code
363832
Product Name
Steel Tube Hydraulic 3m x 1.5mm x 8mm
List Price
£42.90
You Pay
£28.74
You Save
33%
Qty
Steel Tube Hydraulic 3m x 2mm x 8mm
Code
363833
Product Name
Steel Tube Hydraulic 3m x 2mm x 8mm
List Price
£56.05
You Pay
£37.55
You Save
33%
Qty
Steel Tube Hydraulic 3m x 1mm x 10mm
Code
363834
Product Name
Steel Tube Hydraulic 3m x 1mm x 10mm
List Price
£42.90
You Pay
£28.74
You Save
33%
Qty
Steel Tube Hydraulic 6m x 1mm x 10mm
Code
363882
Product Name
Steel Tube Hydraulic 6m x 1mm x 10mm
List Price
£77.95
You Pay
£52.23
You Save
33%
Qty
Steel Tube Hydraulic 3m x 1.5mm x 10mm
Code
363835
Product Name
Steel Tube Hydraulic 3m x 1.5mm x 10mm
List Price
£45.25
You Pay
£30.32
You Save
33%
Qty
Steel Tube Hydraulic 6m x 1.5mm x 10mm
Code
363883
Product Name
Steel Tube Hydraulic 6m x 1.5mm x 10mm
List Price
£81.25
You Pay
£54.44
You Save
33%
Qty
Steel Tube Hydraulic 3m x 2mm x 10mm
Code
363836
Product Name
Steel Tube Hydraulic 3m x 2mm x 10mm
List Price
£57.30
You Pay
£38.39
You Save
33%
Qty
Steel Tube Hydraulic 6m x 2mm x 10mm
Code
363884
Product Name
Steel Tube Hydraulic 6m x 2mm x 10mm
List Price
£90.25
You Pay
£60.47
You Save
33%
Qty
Steel Tube Hydraulic 3m x 1mm x 12mm
Code
363837
Product Name
Steel Tube Hydraulic 3m x 1mm x 12mm
List Price
£46.50
You Pay
£31.16
You Save
33%
Qty
Steel Tube Hydraulic 6m x 1mm x 12mm
Code
363885
Product Name
Steel Tube Hydraulic 6m x 1mm x 12mm
List Price
£82.45
You Pay
£55.24
You Save
33%
Qty
Steel Tube Hydraulic 3m x 1.5mm x 12mm
Code
363838
Product Name
Steel Tube Hydraulic 3m x 1.5mm x 12mm
List Price
£50.05
You Pay
£33.53
You Save
33%
Qty
Steel Tube Hydraulic 6m x 1.5mm x 12mm
Code
363886
Product Name
Steel Tube Hydraulic 6m x 1.5mm x 12mm
List Price
£89.10
You Pay
£59.70
You Save
33%
Qty
Steel Tube Hydraulic 3m x 2mm x 12mm
Code
363839
Product Name
Steel Tube Hydraulic 3m x 2mm x 12mm
List Price
£66.75
You Pay
£44.72
You Save
33%
Qty
Steel Tube Hydraulic 6m x 2mm x 12mm
Code
363887
Product Name
Steel Tube Hydraulic 6m x 2mm x 12mm
List Price
£116.90
You Pay
£78.32
You Save
33%
Qty
Steel Tube Hydraulic 3m x 1.5mm x 14mm
Code
363840
Product Name
Steel Tube Hydraulic 3m x 1.5mm x 14mm
List Price
£58.40
You Pay
£39.13
You Save
33%
Qty
Steel Tube Hydraulic 6m x 1.5mm x 14mm
Code
363888
Product Name
Steel Tube Hydraulic 6m x 1.5mm x 14mm
List Price
£105.85
You Pay
£70.92
You Save
33%
Qty
Steel Tube Hydraulic 3m x 2mm x 14mm
Code
363841
Product Name
Steel Tube Hydraulic 3m x 2mm x 14mm
List Price
£71.85
You Pay
£48.14
You Save
33%
Qty
Steel Tube Hydraulic 6m x 2mm x 14mm
Code
363889
Product Name
Steel Tube Hydraulic 6m x 2mm x 14mm
List Price
£116.30
You Pay
£77.92
You Save
33%
Qty
Steel Tube Hydraulic 3m x 1.5mm x 15mm
Code
363842
Product Name
Steel Tube Hydraulic 3m x 1.5mm x 15mm
List Price
£63.15
You Pay
£42.31
You Save
33%
Qty
Steel Tube Hydraulic 6m x 1.5mm x 15mm
Code
363890
Product Name
Steel Tube Hydraulic 6m x 1.5mm x 15mm
List Price
£111.40
You Pay
£74.64
You Save
33%
Qty
Steel Tube Hydraulic 3m x 2mm x 15mm
Code
363843
Product Name
Steel Tube Hydraulic 3m x 2mm x 15mm
List Price
£85.30
You Pay
£57.15
You Save
33%
Qty
Steel Tube Hydraulic 6m x 2mm x 15mm
Code
363891
Product Name
Steel Tube Hydraulic 6m x 2mm x 15mm
List Price
£139.25
You Pay
£93.30
You Save
33%
Qty
Steel Tube Hydraulic 3m x 1.5mm x 16mm
Code
363844
Product Name
Steel Tube Hydraulic 3m x 1.5mm x 16mm
List Price
£73.90
You Pay
£49.51
You Save
33%
Qty
Steel Tube Hydraulic 6m x 1.5mm x 16mm
Code
363892
Product Name
Steel Tube Hydraulic 6m x 1.5mm x 16mm
List Price
£122.55
You Pay
£82.11
You Save
33%
Qty
Steel Tube Hydraulic 3m x 2mm x 16mm
Code
363845
Product Name
Steel Tube Hydraulic 3m x 2mm x 16mm
List Price
£77.40
You Pay
£51.86
You Save
33%
Qty
Result Pages:
Displaying 1 to 30 (of 103 products)
