Plasson Imperial Fittings

Plasson Imperial Fittings provide a reliable and high-performance solution for connecting imperial-sized polyethylene (PE) pipe systems. Manufactured by Plasson, these fittings are WRAS-approved and constructed from robust, long-lasting materials. Designed for ease of installation and a secure, leak-free seal, the fittings are suitable for a wide range of water distribution applications. Whether for repair, expansion, or new installations, they offer compatibility with UK imperial pipe standards and are ideal for above- or below-ground systems.

• Potable Water Systems: WRAS-approved for use in cold water supply networks for residential and commercial properties.
• Agricultural Installations: Commonly used in field irrigation and livestock watering systems using imperial-sized PE pipe.
• Infrastructure & Civil Works: Suitable for utility services using legacy imperial pipe standards.
• Maintenance & Retrofitting: Ideal for repairs or upgrades where existing systems utilise imperial measurements.

• Material Composition:
• Body: High-grade polypropylene
• Nut: Polypropylene
• Split Ring: Polyacetal (POM)
• O-Ring: Nitrile rubber (NBR)
• Connection Type: Compression
• Size Range: Common UK imperial pipe sizes (e.g., ½", ¾", 1", 1¼", etc.)
• Pressure Rating: Up to 16 bar at 20°C (varies with fitting size)
• Temperature Range: 0°C to 40°C (cold water only)
• Approvals: WRAS approved for potable water use
• Colour: Typically black with blue or grey nut (varies by size/model)
• Standards Compliance: Designed by UK imperial dimension standards

• Pipe Preparation

Cut the pipe square and remove any burrs or debris.
Mark the insertion depth to ensure correct fitting engagement.

• Disassembly (if required)

Loosen the compression nut and slide it, along with the split ring and O-ring, onto the pipe.

• Assembly

Insert the pipe into the fitting until it meets the internal stop.
Push the split ring and O-ring into position, then hand-tighten the nut.
Use a strap wrench for final tightening—avoid overtightening.

• Testing

Once all connections are complete, pressurise the system and inspect for leaks.
Re-check fittings after pressure testing to confirm tightness.
