Galvanised Iron Pipe Fittings

 width=

All text and product images are the intellectual property and copyright of Pipestock Limited

Key Features / Tech Specs:

  • Material: malleable iron (Galvanised)
  • Maximum operating pressure: 25 bar (362 psi)
  • Operating temperature range: -20°C to 120°C (25 bar) or 300°C (20 bar)
  • EE malleable iron fittings are grade W40-05 according to ISO5922/DIN-1692, and tested in accordance to EN 10242
  • All thread types are in accordance to IS07-1
  • All thread types are male BSPT and female BSPP


Useful Info:

EE malleable iron pipe fittings are ideally suited for the flow of water, steam, gas or other non aggressive media.

Galvanised Fittings have a zinc coating to provide resistance to rust and weathering. Galvanisation meets standards EN 10242 and has an average layer thickness 70 micron.



If you require any further information then don’t hesitate to ring us here at Pipestock on 0845 634 1053. We’re always happy to help!
