Thread Type: JIS (Japanese Industrial Standard) BSPP (British Standard Parallel Pipe)
Standard Compliance: Manufactured to BS EN 10277
Temperature Range: -40°C to +120°C (no pressure reduction)
Pressure Ratings:
Proof Pressure: 2× working pressure
Burst Pressure: 4× working pressure
Torque Guidance: Recommended torque values for lightly oiled steel threads
Quality Assurance: Produced under ISO 9001-certified processes
Description
This JIS hexagon blanking cap with BSPP female threads is designed to seal and protect unused JIS hydraulic connections. Manufactured by Burnett & Hillman from high-quality mild steel to BS EN 10277 standards, it provides a robust, leak-proof closure suitable for hydraulic and pneumatic systems. The hexagonal design allows easy tightening with a standard spanner, ensuring secure and reliable port sealing.
Key Features & Benefits
Durable Construction: Mild steel for strong, long-lasting performance
Thread Type: JIS BSPP female thread for compatibility with JIS BSPP male fittings
Leak-Proof Closure: Ensures secure blanking of unused hydraulic connections
Hexagonal Design: Enables easy installation and removal with a standard wrench
Standard Compliance: Manufactured to BS EN 10277 for precise and consistent threading
Versatile Application: Suitable for hydraulic and pneumatic systems using JIS BSPP fittings
Quality Manufacturing: ISO 9001-certified production ensures reliable product quality
Burnett & Hillman Pressure Guide
SKU
Product Code
T1 (")
O/L (")
A/F (")
380489
7691-04
1/4
0.740
19
380490
7691-06
3/8
0.880
22
380491
7691-08
1/2
0.770
27
380492
7691-12
3/4
0.985
32
IMPORTANT: The technical data given on this website is for preliminary information purposes only and is published without guarantee. All line drawings are for illustrative purposes only and should not be regarded as wholly accurate in every detail. We reserve the right to withdraw or to alter the specification of any product without notice. For more information, please consult our Terms of Business.
