Air-Pro Nylon Tube Imperial
Useful Information
Technical Specification
- Material: PA12 Semi-Rigid (Polyamide 12), food grade
- External diameter range: 1/8" to 5/8"
- Coil length: 30 metres
- Temperature range: -40°C to +110°C continuous, +140°C intermittent
- Maximum working pressure: up to 66 bar (967 psi)
- Conformance: FDA and EU regulations for direct contact with non-alcoholic foodstuffs
- Shore-D Hardness: 70
- Flame Rating: UL 94 HB
Description
Manufactured from high-viscosity PA12, this semi-rigid nylon tubing is lightweight, highly durable, and designed for consistent performance across demanding environments. It boasts low water absorption, excellent resistance to most chemicals including dilute acids and alkalis, and remains tough even in extreme low temperatures. Supplied in 30 metre imperial coils, it is ideal for use across pneumatic control systems, fuel lines, lubrication systems, and food and beverage processing lines.
Key Features & Benefits
- Excellent mechanical strength and dimensional stability
- Low water absorption and tasteless material - ideal for food-grade applications
- Resists abrasion and weathering for extended service life
- Operates across a wide temperature range from -40°C to +140°C
- Suitable for pneumatic, automotive, and industrial applications
- Approved for direct food contact (non-alcoholic), complying with FDA and EU standards
- Available in multiple imperial sizes to suit various installations
| Product Code | ID (inch) | OD (inch) | Max. Working Pressure (psi) |
| 377794 | 0.075 | 1/8 | 967 |
| 377795 | 0.117 | 3/16 | 868 |
| 377796 | 0.170 | 1/4 | 683 |
| 377797 | 0.212 | 5/16 | 684 |
| 377798 | 0.250 | 3/8 | 725 |
| 377799 | 0.375 | 1/2 | 483 |
| 377800 | 0.500 | 5/8 | 363 |
