Kelm Metric Swivel Tee 90° Run M
Useful Information
Technical Specification
- Material: Nickel-Plated Brass with POM Sleeve
- Media Compatibility: Air and Vacuum Only
- Thread Type: Metric Male (M5x0.8)
- Tube Connection: 4mm Outside Diameter
- Maximum Pressure: 10 bar
- Operating Temperature Range: 0°C to +60°C
- Thread Gender: Male (Run Leg)
- Fitting Type: 90° Swivel Run Tee
- Negative Pressure Capability: -750mm Hg (-750 Torr)
Description
This compact swivel tee is ideal for applications requiring a 90° run connection with a central male threaded outlet. The male run leg rotates, allowing for flexible positioning during installation without compromising seal integrity. Featuring one-touch push-in ports for quick and tool-free tube connection, it offers a streamlined solution for routing compressed air or vacuum lines. Built from nickel-plated brass and fitted with a durable POM sleeve, it ensures long-lasting performance in industrial environments.
Key Features & Benefits
- Rotating Run Leg: Swivel function allows easy thread alignment post-installation
- 90° Tee Design: Ideal for inline branching of pneumatic circuits
- Quick Connection: One-touch push-in ports enable rapid tube assembly
- Reliable Sealing: Teflon-treated threads enhance leak prevention
- Corrosion Resistant: Nickel-plated brass ensures long service life in demanding conditions
- Vacuum Suitability: Performs under negative pressure conditions down to -750mm Hg
| Product Code | D (mm) | R (Thread) | P (mm) | A (mm) | B (mm) | C (mm) | E (mm) | F (mm) | H (mm) | d (mm) |
| 366327 | 4 | M5x0.8 | 10 | 4 | 25 | 15.5 | 17.5 | 8 | 10 | 3.2 |
