Reducing Bush M x F BSPT
Useful Information
Technical Specification
- Manufacturer: Tefen
- Connection Type: BSPT Male x Female (Reducing Bush)
- Thread Type: BSPT (British Standard Pipe Taper)
- Thread Genders: Male x Female
- Working Temperature: -20°C to +120°C
- Max. Working Pressure: Up to 14 bar (200 psi) at +12°C
Description
This reducing bush is designed to connect two BSPT threaded fittings of different sizes, providing a compact and leak-resistant transition within hydraulic and pneumatic systems. Made from PVDF, it offers superior resistance to a wide range of corrosive chemicals and elevated temperatures. The fitting delivers high mechanical strength and long-term reliability in aggressive industrial environments.
Key Features & Benefits
- Allows secure thread size reduction in confined systems
- Excellent chemical resistance to acids, alkalis, halogens, and solvents
- Suitable for use in chemically harsh and thermally demanding applications
- Durable construction prevents thread distortion and pullout
- Ideal for fluid transfer, water treatment, and chemical processing systems
- Outperforms nylon in corrosive and high-temperature environments
| Product Code | M BSPT (inch) | F BSPT (inch) | L (mm) | SW |
| 378095 | 1/4 | 1/8 | 17.2 | 14 |
| 378096 | 3/8 | 1/8 | 17.8 | 17 |
| 378097 | 3/8 | 1/4 | 17.8 | 17 |
| 378098 | 1/2 | 1/8 | 20.7 | 22 |
| 378099 | 1/2 | 1/4 | 20.4 | 22 |
| 378100 | 1/2 | 3/8 | 20.7 | 22 |
If you require any further information, our excellent customer service team is here to help so please call us on 01794 835835.
