ABS Inch Elbow 90° Plain

Loading...
main product photo
More Info
Useful Information

Technical Specification

  • Material: ABS (Acrylonitrile Butadiene Styrene)
  • Pressure Rating: 16 bar at 20°C
  • Operating Temperature Range: -40°C to +60°C
  • Size Range: 1/2" to 8"
  • Application: Forming 90° pipe connections with matching diameters

Description

Effast plain ABS 90° elbow fittings are designed to join two lengths of ABS pipe of the same diameter at a right angle. Manufactured from robust ABS material, these fittings offer a lightweight, durable, and corrosion-resistant solution, ideal for a wide range of industrial and commercial installations. Available in sizes from ½" to 8", they provide a reliable connection capable of withstanding high pressure and varying temperatures.

Key Features & Benefits

  • Joins two ABS pipes of identical diameter at a 90° angle
  • Strong, lightweight, and corrosion-resistant ABS construction
  • Effective operation between -40°C and +60°C
  • Manufactured by the trusted brand Effast



ABS Elbow 90 Plain Diagram

SKU Supplier Code Nominal Size (inch) L (mm) Z (mm) E (mm)
353124 AFAGOA0200 1/2 17 11 27
353125 AFAGOA0250 3/4 20 14 33
353126 AFAGOA0320 1 23 17 41
353127 AFAGOA0400 1 1/4 27 22 51
353128 AFAGOA0500 1 1/2 32 26 61
353129 AFAGOA0630 2 37 34 75
353130 AFAGOA0750 2 1/2 44 39 90
353131 AFAGOA0900 3 52 45 107
353132 AFAGOA1100 4 63 59 133
353133 AFAGOA1400 5 79 68 164
353134 AFAGOA1600 6 93 85 198
353135 AFAGOA2250 8 116 116 253



IMPORTANT: The technical data given on this website is for preliminary information purposes only and is published without guarantee. All line drawings are for illustrative purposes only and should not be regarded as wholly accurate in every detail. We reserve the right to withdraw or to alter the specification of any product without notice. For more information, please consult our Terms of Business.

If you require any further information, our excellent customer service team is here to help so please call us on 01794 835835.



More Info
Grouped product items
Code Product Name List Price You Save You Pay Quantity
353124 ABS Elbow 90 Plain 1/2" £4.74 80%
You Pay:  £0.95
353125 ABS Elbow 90 Plain 3/4" £5.67 80%
You Pay:  £1.13
353126 ABS Elbow 90 Plain 1" £7.74 80%
You Pay:  £1.55
353127 ABS Elbow 90 Plain 1 1/4" £13.28 80%
You Pay:  £2.66
353128 ABS Elbow 90 Plain 1 1/2" £17.15 80%
You Pay:  £3.43
353129 ABS Elbow 90 Plain 2" £25.90 80%
You Pay:  £5.18
353130 ABS Elbow 90 Plain 2 1/2" £49.82 80%
You Pay:  £9.96
353131 ABS Elbow 90 Plain 3" £74.70 80%
You Pay:  £14.94
353132 ABS Elbow 90 Plain 4" £111.42 80%
You Pay:  £22.28
353133 ABS Elbow 90 Plain 5" £256.99 80%
You Pay:  £51.40
353134 ABS Elbow 90 Plain 6" £446.70 80%
You Pay:  £89.34
353135 ABS Elbow 90 Plain 8" £902.34 80%
You Pay:  £180.47
