ABS Inch Bend 90° Plain

Loading...
main product photo
More Info
Useful Information

Technical Specification

  • Material: ABS (Acrylonitrile Butadiene Styrene)
  • Pressure Rating: 16 bar at 20°C
  • Operating Temperature Range: -40°C to +60°C
  • Size Range: 1/2" to 4"
  • Application: Forming smooth 90° connections between matching diameter pipes

Description

Effast plain ABS 90° bend fittings are designed to connect two lengths of ABS pipe of the same diameter at a 90° angle with a smoother radius than a standard elbow. Manufactured from high-quality ABS material, these fittings provide a lightweight, durable, and corrosion-resistant solution, ideal for a variety of industrial and commercial applications. Available in sizes from ½" to 4", they maintain excellent performance under high pressure and varying temperatures.

Key Features & Benefits

  • Connects two ABS pipes of identical diameter at a 90° angle
  • Smoother radius for improved flow compared to standard elbows
  • Durable, lightweight, and corrosion-resistant ABS construction
  • Operational temperature range from -40°C to +60°C
  • Manufactured by trusted supplier Effast



ABS Bend 90 Plain Diagram

SKU Supplier Code Nominal Size (inch) L (mm) Z (mm) E (mm)
353086 AFACUA0200 1/2 17 40 30
353087 AFACUA0250 3/4 20 50 36
353088 AFACUA0320 1 23 64 44
353089 AFACUA0400 1 1/4 27 80 54
353090 AFACUA0500 1 1/2 32 100 63
353091 AFACUA0630 2 39 126 78
353092 AFACUA0750 2 1/2 44 150 94
353093 AFACUA0900 3 51 180 113
353094 AFACUA1100 4 63 220 133



IMPORTANT: The technical data given on this website is for preliminary information purposes only and is published without guarantee. All line drawings are for illustrative purposes only and should not be regarded as wholly accurate in every detail. We reserve the right to withdraw or to alter the specification of any product without notice. For more information, please consult our Terms of Business.

If you require any further information, our excellent customer service team is here to help so please call us on 01794 835835.



More Info
Grouped product items
Code Product Name List Price You Save You Pay Quantity
353086 ABS Bend 90 Swept Plain 1/2" £17.29 80%
You Pay:  £3.46
353087 ABS Bend 90 Swept Plain 3/4" £20.15 80%
You Pay:  £4.03
353088 ABS Bend 90 Swept Plain 1" £29.59 80%
You Pay:  £5.92
353089 ABS Bend 90 Swept Plain 1 1/4" £42.43 80%
You Pay:  £8.49
353090 ABS Bend 90 Swept Plain 1 1/2" £53.14 80%
You Pay:  £10.63
353091 ABS Bend 90 Swept Plain 2" £91.09 80%
You Pay:  £18.22
353092 ABS Bend 90 Swept Plain 2 1/2" £146.62 80%
You Pay:  £29.32
353093 ABS Bend 90 Swept Plain 3" £180.26 80%
You Pay:  £36.05
353094 ABS Bend 90 Swept Plain 4" £360.76 80%
You Pay:  £72.15
