Stainless Steel Barrel Nipple
Useful Information
Key Features / Tech Specs:
- Material: stainless steel - CF8M (316)
- Conforms to ISO 4144 standard
- Operating temperature range of -20°C to 220°C
Technical Info:
Â
| Nominal Diameter (inch) | A (mm) | B (mm) | Weight (kg) |
| â…› | 10.2 | 30 | 0.009 |
| ¼ | 13.5 | 30 | 0.012 |
| ⅜ | 17.2 | 40 | 0.024 |
| ½ | 21.3 | 60 | 0.063 |
| ¾ | 26.9 | 60 | 0.083 |
| 1 | 33.7 | 60 | 0.12 |
| 1¼ | 42.4 | 80 | 0.211 |
| 1½ | 48.3 | 80 | 0.256 |
| 2 | 60.3 | 100 | 0.44 |
| 2½ | 76.1 | 100 | 0.69 |
| 3 | 88.9 | 120 | 1.16 |
| 4 | 114.3 | 120 | 1.477 |
If you require any further information, our excellent customer service team is here to help so please call us on 01794 835835.
