Prevost Medium Pressure Rubber Oil Hose Reel

• Media Type: Oil
• Hose Material: Rubber
• Hose Length Options: 10, 15 or 20m
• Max Operating Pressure: 60 bar
• Operating Temperature: -10°C to 40°C
• Net Weight: 18.5 to 27kg (depending on model)
• Case Material: Galvanised steel with UV-resistant polyester coating
• Auto Rewind: System to retract the hose automatically
• Mounting Options: Wall or ceiling
• Adjustable Stop: Holds the hose at the desired length

This reel is purpose-built for managing oil lines in industrial settings requiring medium pressures. Supplied pre-hosed with a 13 × 19 mm rubber hose compatible with oil media, it supports pressures up to 60 bar. The open steel drum (with epoxy coating) offers strength and resilience, while the ratchet stop mechanism ensures the hose remains at the desired extension during use. The fixed bracket mount simplifies installation and ensures stable performance. The temperature range of –10 °C to +40 °C matches typical environments for oil handling systems. It’s ideal for workshops, maintenance depots, or factory floors where controlled, reliable oil dispensing is required.

• Safety Spring Mechanism: Provides a controlled hose return, preventing rapid retraction that could cause injury or damage.
• Anti-Whiplash Coupling: Allows for the safe decompression and disconnection of pneumatic tools in a single movement, preventing hose whip and potential injuries.
• Locking System: Holds the hose at the desired length, allowing users to work comfortably without hose pullback.
• Anti-Twist Pipe Protectors: Prevents the hose from twisting, ensuring smooth operation and extending the hose's lifespan.
• Limit Switch: Enhances user control by limiting the hose retraction point.
• Galvanised Steel Housing: Features a UV-resistant polyester-based electrostatic powder coating that protects against corrosion and wear, ensuring durability even in harsh environments.
• 360-Degree Rotating Oil Inlet: Connected via a 1-metre supply hose.
