Walraven Pan Head Concrete Screw

The pan-head concrete screw is engineered to deliver reliable anchorage in demanding concrete environments. Featuring a pan-head and Torx T30 drive, it offers ease of installation and robust performance. The zinc-plated steel construction ensures durability and corrosion resistance. Thanks to its tip and thread geometry, the risk of spalling in the substrate is minimised. Suitable for cracked and non-cracked concrete as well as hollow-core slabs, this screw supports demanding structural and mechanical fixings and offers fire-resistance up to R120 to meet stringent safety standards.

• High load capacity: Enables secure mounting of heavy structural or mechanical components.
• Pan-head design with large head: Ensures strong bearing under the fixture and good load distribution.
• Torx T30 drive: Facilitates efficient installation with standard tools and reduces cam-out risk.
• Multiple anchoring depths: Offers flexibility for different concrete thicknesses and substrate conditions.
• Reduced edge and anchor spacing: Enables efficient layout close to edges or adjacent anchors, saving space.
• Minimised spalling through special tip and thread geometry: Protects the substrate integrity during installation.
• Fire-rated R30–R120: Supports installations where fire resistance is critical.
• Approved for sprinkler-system use in concrete elements: Complies with VdS CEA 4001:2014-04 and VdS CEA 4001:2018-01 certification, assuring reliability for fire-protection systems.
• Versatile substrate compatibility: Covering cracked, non-cracked concrete and hollow-core slabs broadens the application range.
