MDPE Pipe Blue Coils

main product photo
More Info
Useful Information

Our blue MDPE pipe coils are available in sizes 20mm to 180mm.

Blue MDPE pipe is also referred to as alkathene pipe, PE pipe, blue water pipe, PE80 pipe, and even Polypipe, and is approved for below ground and potable water applications.

Pipe cannot be returned, no refunds or exceptions. This is due to the Bespoke, Physical and Technical characteristics of this industrial product. Please double-check your application and sizing, if in doubt call us, we are here to help.

Pressure Rating (MDPE) 12.5 bar
Pressure Rating (HDPE) 10 bar
Standards ISO 4427:2007, BS EN 15494:2003, BS 6572:1985, BS EN 12201



Approvals:

WRAS Approved Product - sold by Pipestock WRAS approved
BSI Kitemark Approved Product - sold by Pipestock

BSI Kitemark approved

Licence number KM85017



MDPE Pipe Dimensions, Metric, BS EN 15494:2003

Pipe Size (mm) Average Bore Inside Diameter (mm) Average Wall Thickness (mm) Approximate Weight per Metre (kg)  PE Rating SDR Rating
20 15.2 2.4 0.13 80 11
25 20.1 2.5 0.17 80 11
32 25.8 3.1 0.28 80 11
50 40.4 4.8 0.67 80 11
63 50.9 6.1 1.05 80 11
90 78.7 5.7 1.39 100 17
110 96.3 6.9 2.06 100 17
125 109.5 7.8 2.66 100 17
160 140.3 9.8 4.38 100 17
180 158.0 11.0 5.49 100 17



IMPORTANT: The technical data given on this website is for preliminary information purposes only and is published without guarantee. All line drawings are for illustrative purposes only and should not be regarded as wholly accurate in every detail. We reserve the right to withdraw or to alter the specification of any product without notice. For more information, please consult our Terms of Business.



When ordering pipe coils that are 50mm and above, please consider the weight and bulk of what you are ordering. An MDPE pipe that is 50m x 63mm weighs approximately 50kgs; anything above this will need to be off-loaded and manoeuvered by mechanical means. The following pipe sizes have to be delivered by our own dedicated transport and not by standard courier:

  • 100m x 50mm
  • 150m x 50mm
  • 100m x 63mm
  • 150m x 63mm
  • All sizes and lengths from 90mm to 180mm

If you do not have mechanical offloading capabilities available on-site, please ring us to discuss the options.



If you require any further information, our excellent customer service team is here to help so please call us on 01794 835835.



More Info
Grouped product items
CodeProduct NameList PriceYou SaveYou Pay Quantity
354901MDPE Pipe Blue 12.5 Bar 25m x 20mm £27.98 50%
£13.99
354906MDPE Pipe Blue 12.5 Bar 50m x 20mm £55.98 50%
£27.99
354916MDPE Pipe Blue 12.5 Bar 100m x 20mm £111.98 50%
£55.99
354926MDPE Pipe Blue 12.5 Bar 150m x 20mm £173.98 50%
£86.99
354902MDPE Pipe Blue 12.5 Bar 25m x 25mm £35.98 50%
£17.99
354907MDPE Pipe Blue 12.5 Bar 50m x 25mm £71.98 50%
£35.99
354917MDPE Pipe Blue 12.5 Bar 100m x 25mm £145.98 50%
£72.99
354927MDPE Pipe Blue 12.5 Bar 150m x 25mm £219.98 50%
£109.99
354903MDPE Pipe Blue 12.5 Bar 25m x 32mm £59.98 50%
£29.99
354908MDPE Pipe Blue 12.5 Bar 50m x 32mm £119.98 50%
£59.99
354918MDPE Pipe Blue 12.5 Bar 100m x 32mm £239.98 50%
£119.99
354928MDPE Pipe Blue 12.5 Bar 150m x 32mm £365.98 50%
£182.99
354904MDPE Pipe Blue 12.5 Bar 25m x 50mm £145.10 50%
£72.55
354909MDPE Pipe Blue 12.5 Bar 50m x 50mm £290.12 50%
£145.06
354919MDPE Pipe Blue 12.5 Bar 100m x 50mm £580.28 50%
£290.14
354929MDPE Pipe Blue 12.5 Bar 150m x 50mm £870.40 50%
£435.20
354905MDPE Pipe Blue 12.5 Bar 25m x 63mm £226.54 50%
£113.27
354910MDPE Pipe Blue 12.5 Bar 50m x 63mm £452.98 50%
£226.49
354920MDPE Pipe Blue 12.5 Bar 100m x 63mm £906.04 50%
£453.02
354930MDPE Pipe Blue 12.5 Bar 150m x 63mm £1,359.02 50%
£679.51
354911HDPE Pipe Blue 10 Bar 50m x 90mm ** £1,453.24 50%
£726.62
354921HDPE Pipe Blue 10 Bar 100m x 90mm ** £2,906.52 50%
£1,453.26
354912HDPE Pipe Blue 10 Bar 50m x 110mm ** £2,141.28 50%
£1,070.64
354922HDPE Pipe Blue 10 Bar 100m x 110mm ** £4,282.56 50%
£2,141.28
354913HDPE Pipe Blue 10 Bar 50m x 125mm ** £2,752.10 50%
£1,376.05
354923HDPE Pipe Blue 10 Bar 100m x 125mm ** £5,504.22 50%
£2,752.11
354914HDPE Pipe Blue 10 Bar 50m x 160mm ** £4,482.38 50%
£2,241.19
354924HDPE Pipe Blue 10 Bar 100m x 160mm ** £8,964.79 50%
£4,482.39
354915HDPE Pipe Blue 10 Bar 50m x 180mm ** £5,690.40 50%
£2,845.20
354925HDPE Pipe Blue 10 Bar 100m x 180mm ** £11,380.83 50%
£5,690.42

**Due to carrier size limits, these larger coils require a minimum MDPE pipe order value of £2000. For orders below this, contact us on 01794 835835.
