Application: Mains water isolation for 50mm and 63mm pipe systems
Description
This mains stop valve with drain ports is constructed from glass-reinforced polyamide, providing a robust, non-metallic solution for lead-free water control. Designed specifically for above-ground installations, it features two integrated drain ports for system maintenance and safe drainage. The quarter-turn ball valve mechanism allows for full bore operation, minimising head loss. Rated to 16 bar, this valve is WRAS approved and is the first of its kind certified for use on 50mm and 63mm mains water pipes.
Key Features & Benefits
Dual Drain Ports: Integrated ports allow for easy drainage and system maintenance.
Non-Metallic Build: Made from glass-reinforced polyamide for lead-free, corrosion-resistant performance.
WRAS Approved: First non-metallic stop valve approved for 50mm and 63mm mains water pipes.
Full Bore Flow: Quarter-turn ball valve ensures minimal head loss and high flow capacity.
High Pressure Rating: Handles up to 16 bar, suitable for high-demand installations.
Above-Ground Use: Specifically designed for above-ground applications only.
Dimensions
SKU
Supplier Code
Size (inch)
DN (mm)
A1 (mm)
A2 (mm)
H (mm)
I (mm)
B (mm)
E (mm)
W (mm)
374314
PV037030F007
3/4
20
27
54
97
17
36
53
175
374315
PV037030F010
1
25
33
64
116
21
46
64
313
374316
PV037030F013
1 1/4
32
36
70
118
20
55
73
393
374317
PV037030F015
1 1/2
40
45
87
144
24
65
91
712
374318
PV037030F020
2
50
53
97
162
29
75
100
918
