Shuttle Valves

Shuttle Valves

Click on the image to activate zoom.

All text and product images are the intellectual property and copyright of Pipestock Limited

Key Features / Tech Specs:

  • Material: mild steel
  • Manufactured to DIN 2353
  • Ball seat
  • Series L (light)

Eaton Shuttle Valve L

Product Code Outer Diameter (mm) L5 (mm) L2 (mm) l (mm) S1 (mm) S2 (mm) Max. Pressure (bar)
365593 8 21 29 14 14 17 250
365594 10 22 30 15 17 19 250
365595 12 24 32 17 19 22 250



If you require any further information then don’t hesitate to ring us here at Pipestock on 0845 634 1053. We’re always happy to help!
