Marine Fuel Hose A1
Useful Information
Technical Specification
- Reinforcement: Synthetic textile (Type A1)
- Operating Pressure: Up to 10 bar
- Temperature Range: -35°C to +100°C
- Resistance: Abrasion, weather, heat, ozone, oil, and fuel resistant
- Compliance: ISO 7840 Type A1
- Available Lengths: 10 and 40 metres
- Internal Diameter Range: 5mm to 19mm
- Outer Diameter Range: 12mm to 29mm
Description
Specifically designed for marine fuel systems, this ISO 7840 Type A1 certified hose is ideal for the conveyance of diesel and petrol in engine compartments or fuel delivery systems on boats and marine craft. Constructed with a black NBR rubber inner tube and a durable neoprene outer cover, it provides robust resistance against abrasion, weathering, oil, and fuel exposure. The hose is reinforced with high-strength synthetic textile to maintain stability and performance under pressure. Available in a wide range of diameters and lengths to suit various marine applications.
Key Features & Benefits
- ISO 7840 Type A1 approved for marine fuel use
- Suitable for diesel and petrol transfer on marine vessels
- Strong synthetic textile reinforcement maintains hose integrity
- Neoprene cover resists abrasion, oil, ozone, and extreme weather
- Operates reliably from -35°C to +100°C
- 10 bar working pressure with a 3:1 safety factor
- Available in convenient 10m and 40m coil lengths
| Dimensions and Weight | |||
| Product Code | Internal Diameter (mm) | External Diameter (mm) | Length (m) |
| 372556 | 5 | 12 | 10 |
| 372557 | 5 | 12 | 40 |
| 372558 | 6 | 13 | 10 |
| 372559 | 6 | 13 | 40 |
| 372560 | 8 | 16 | 10 |
| 372561 | 8 | 16 | 40 |
| 372562 | 10 | 18 | 10 |
| 372563 | 10 | 18 | 40 |
| 372564 | 13 | 22 | 10 |
| 372565 | 13 | 22 | 40 |
| 372566 | 16 | 25 | 10 |
| 372567 | 16 | 25 | 40 |
| 372568 | 19 | 29 | 10 |
| 372569 | 19 | 29 | 40 |
