This Type E camlock fitting features a robust brass barbed hose tail, designed for secure insertion into flexible hose lines. Its cam and groove configuration allows for fast, reliable connections without the need for tools. This fitting is well-suited for a range of industrial and fluid handling applications where durable and quick coupling is essential.
Key Features & Benefits
Solid brass construction ensures durability and corrosion resistance
Barbed hose tail delivers a firm, secure grip in hose assemblies
Compatible with camlock couplers for quick and easy connections
Rated to a maximum working pressure of 17 bar
Ideal for use in fluid transfer, washdown, and general industrial systems
SKU
A (mm)
B (mm)
C (mm)
D (mm)
E (mm)
F (mm)
Pressure (psi)
358545
8
85
24
14
23
41
250
358546
18.7
87
32.1
21.5
26
47.8
250
358547
19.5
93
36.73
27.4
33.8
55
250
358548
31.3
100
45.52
34.1
39
57
250
358549
30.8
111
53.34
39.6
41
70.5
150
358550
43
124
63.09
52.4
46
82
150
358551
56
141
75.82
66.6
48
87
150
358552
74
152
91.5
77.8
50
92
125
358553
91.8
160
119.58
103.2
52.8
103.5
125
IMPORTANT: The technical data given on this website is for preliminary information purposes only and is published without guarantee. All line drawings are for illustrative purposes only and should not be regarded as wholly accurate in every detail. We reserve the right to withdraw or to alter the specification of any product without notice. For more information, please consult our Terms of Business.
If you require any further information, our excellent customer service team is here to help so please call us on 01794 835835.
