Reducing Coupling PE x PE NBR

Useful Information

These PRIMOFIT compression reducing couplings have NBR gaskets and are for connection to PE SDR 11/S 5.



Material Malleable Iron
Colour Black
Pressure Rating up to 16 bar - Water only
Operating Temperature -20°C to +80°C

GF-primofit-reducing-coupling-diagram

Product Code Dim. (mm) D (mm) D1 (mm) L (mm) x (mm) x1 (mm) Weight (kg)
399683 25 x 2.3 - 20 x 2.0 51 45 87 31 - 33 31 - 33 0.412
399684 32 x 3.0 - 20 x 2.0 59 45 94 31 - 33 31 - 33 0.455
399685 32 x 3.0 - 25 x 2.3 59 51 94 31 - 33 31 - 33 0.547



If you require any further information, our excellent customer service team is here to help so please call us on 01794 835835.



Grouped product items
CodeProduct NameList PriceYou SaveYou Pay Quantity
399683GF PF Red. Coupling PE x PE Galv. NBR 25mm x 20mm £42.36 5% £40.24
399684GF PF Red. Coupling PE x PE Galv. NBR 32mm x 20mm £47.40 5% £45.03
399685GF PF Red. Coupling PE x PE Galv. NBR 32mm x 25mm £47.40 5% £45.03
