Socket Plain x Thread F

Useful Information

These ecoFIT socket-fusion fittings, from Georg Fischer, are manufactured from heavy-duty and corrosion-resistant PE80 polyethylene for pipeline construction. They are suitable for conveying gas and water through ground-layed pipe systems.

These socket adaptors have a fusion socket and a parallel female threaded socket with a stainless steel reinforcing ring for connection to plastic or metal threaded fittings.

Pressure Rating 10 bar
Temperature Range -50°C to +60°C
Sizes 20mm x 1/2" - 63mm x 2"
Colour Black - RAL 9005

GF-plain-x-thread-adaptor-socket-diagram

Product Code d (mm) Rp (inch) z (mm) L (mm) s (mm) Weight (kg)
401997 20 1/2 7 35 32 0.020
401998 25 3/4 7 39 36 0.026
401999 32 1 7 45 46 0.042
402000 40 1 1/4 7 53 55 0.068
402001 50 1 1/2 9 54 65 0.098
402002 63 2 9 62 80 0.155



If you require any further information, our excellent customer service team is here to help so please call us on 01794 835835.



Grouped product items
CodeProduct NameList PriceYou SaveYou Pay Quantity
401997GF ecoFIT SF PE Socket x Thread F 10 Bar 20mm x 1/2" £11.73 20% £9.38
401998GF ecoFIT SF PE Socket x Thread F 10 Bar 25mm x 3/4" £14.93 20% £11.94
401999GF ecoFIT SF PE Socket x Thread F 10 Bar 32mm x 1" £19.00 20% £15.20
402000GF ecoFIT SF PE Socket x Thread F 10 Bar 40mm x 1 1/4" £23.43 20% £18.74
402001GF ecoFIT SF PE Socket x Thread F 10 Bar 50mm x 1 1/2" £37.94 20% £30.35
402002GF ecoFIT SF PE Socket x Thread F 10 Bar 63mm x 2" £51.82 20% £41.46
