SX Easyfit Air Release Valve

Useful Information

Key Features / Tech Specs:

  • Body Material: acrylonitrile butadiene styrene (ABS)
  • Seal Material : Ethylene Propylene Diene Terpolymer (EPDM)
  • DWI approved
  • Sizes ½" to 2" available
  • Max Working Pressure 16 bar



ABS-Check-Valve-Size-Diagram

Product Code d (Inch) L (mm) Z (mm) H (mm) E (mm) DN
368885 1/2 16.5 50 82 54 15
368886 3/4 19 53 91 63 20
368887 1 22.5 59 103 72 25
368888 1 1/4 26 68 120 85 32
368889 1 1/2 30 77 139 100 40
368890 2 36 98 174 118 50



IMPORTANT: The technical data given on this website is for preliminary information purposes only and is published without guarantee. All line drawings are for illustrative purposes only and should not be regarded as wholly accurate in every detail. We reserve the right to withdraw or to alter the specification of any product without notice. For more information, please consult our Terms of Business.

Approvals:

DWI Approved Product - sold by Pipestock



If you require any further information, our excellent customer service team is here to help so please call us on 01794 835835.



Grouped product items
CodeProduct NameList PriceYou SaveYou Pay Quantity
368885DP ABS SX Easyfit Air Release Valve EPDM Plain 1/2" £158.08 30% £110.66
368886DP ABS SX Easyfit Air Release Valve EPDM Plain 3/4" £168.36 30% £117.85
368887DP ABS SX Easyfit Air Release Valve EPDM Plain 1" £224.78 30% £157.35
368888DP ABS SX Easyfit Air Release Valve EPDM Plain 1 1/4" £224.17 30% £156.92
368889DP ABS SX Easyfit Air Release Valve EPDM Plain 1 1/2" £326.66 30% £228.66
368890DP ABS SX Easyfit Air Release Valve EPDM Plain 2" £504.07 30% £352.85
