Durapipe ABS Plain 3-Way Ball Valve L-Port Inch

Useful Information

Key Features / Tech Specs:

  • Valve material: acrylonitrile butadiene styrene (ABS)
  • Imperial plain ends
  • Sizes: 1/2" to 2"
  • L-Port - 4 positions
  • ATEX EX112GDc approved actuator

Useful info:

Actuator:

The pneumatic actuator from Prisma offers a rotation angle from 0-90° with a working temperature between -32°C & 90°C and a maximum pilot pressure of 8 bar.

It has a Polyamide body and is SIL2 rated meaning it is free from silicon. It has double-acting torques from 17 to 165.5Nm at 6 bar.

Valves:

The TK 3-way valves are manufactured by Durapipe and offer full DWI approval across the range.

They have an ABS body with EPDM seals and offer a maximum working pressure of 15 bar.



If you require any further information, our excellent customer service team is here to help so please call us on 01794 835835.



Grouped product items
CodeProduct NameList PriceYou SaveYou Pay Quantity
391724DP ABS Pneum Act TKD 3-Way Ball Valve L Port Plain 1/2" £305.47 30%
£213.83
391725DP ABS Pneum Act TKD 3-Way Ball Valve L Port Plain 3/4" £329.71 30%
£230.80
391726DP ABS Pneum Act TKD 3-Way Ball Valve L Port Plain 1" £524.45 30%
£367.12
391727DP ABS Pneum Act TKD 3-Way Ball Valve L Port Plain 1 1/4" £590.31 30%
£413.22
391728DP ABS Pneum Act TKD 3-Way Ball Valve L Port Plain 1 1/2" £612.94 30%
£429.06
391729DP ABS Pneum Act TKD 3-Way Ball Valve L Port Plain 2" £798.12 30%
£558.68
