VXE DU Ball Valve EPDM

Useful Information

Key Features / Tech Specs:

  • Body Material: acrylonitrile butadiene styrene (ABS)
  • Seal Material: EPDM
  • DWI approved
  • Sizes 1/2" to 2" available
  • Max. Pressure 16 bar

ABS-Ball-Valve-Diagram


Product Code Nominal Size (inch) L (mm) Z (mm) H (mm) E (mm) B (mm) C (mm) C1 (mm) DN PN
368867 1/2 16.5 49 82 54 49 64 20 15 16
368868 3/4 19 53 91 63 62 78 23 20 16
368869 1 22.5 58 103 72 71 87 27 25 16
368870 1 1/4 26 68 120 85 82 102 30 32 16
368871 1 1/2 30 79 139 100 92 109 33 40 16
368872 2 36 102 174 118 110 133 39 50 16



Approvals:

DWI Approved Product - sold by Pipestock



Useful Info:

Solvent Cement required for joining this product with other ABS systems.

Union Fittings allow for easy maintenance of the valve without the need for additional gluing.



IMPORTANT: The technical data given on this website is for preliminary information purposes only and is published without guarantee. All line drawings are for illustrative purposes only and should not be regarded as wholly accurate in every detail. We reserve the right to withdraw or to alter the specification of any product without notice. For more information, please consult our Terms of Business.

If you require any further information, our excellent customer service team is here to help so please call us on 01794 835835.



Grouped product items
CodeProduct NameList PriceYou SaveYou Pay Quantity
368867DP ABS VXE Easyfit DU Ball Valve EPDM 1/2" £73.12 30% £51.18
368868DP ABS VXE Easyfit DU Ball Valve EPDM 3/4" £86.84 30% £60.79
368869DP ABS VXE Easyfit DU Ball Valve EPDM 1" £103.64 30% £72.55
368870DP ABS VXE Easyfit DU Ball Valve EPDM 1 1/4" £132.90 30% £93.03
368871DP ABS VXE Easyfit DU Ball Valve EPDM 1 1/2" £171.18 30% £119.83
368872DP ABS VXE Easyfit DU Ball Valve EPDM 2" £217.79 30% £152.45
