VKR Metering Ball Valve

Useful Information

Key Features / Tech Specs:

  • Body material: acrylonitrile butadiene styrene (ABS)
  • WRAS approved (Approval number 1509035)
  • Seal material: EPDM
  • DWI approved
  • Max. operating pressure: 16 bar

ABS-Metering-Valve-Diagram


Product Code Nominal Size (inch) L (mm) Z (mm) H (mm) H1 (mm) E (mm) B (mm) B1 (mm) C (mm) C1 (mm) DN PN
368860 1/2 16.5 70 103 65 54 54 295 67 40 10 16
368861 3/4 19 77 115 70 65 65 34.5 85 49 20 16
368862 1 22.5 83 128 78 73 73 39 85 49 25 16
368863 1 1/4 26 94 146 88 86 86 46 108 64 32 16
368864 1 1/2 30 104 164 91 98 98 52 108 64 40 16
368865 2 36 127 199 111 122 108 62 134 76 50 16



Approvals:

WRAS Approved Product - sold by Pipestock DWI Approved Product - sold by Pipestock

Useful Info:

Solvent cement is required for joining this product with other ABS systems.

Union fittings allow for easy maintenance of the valve without the need for additional gluing.



IMPORTANT: The technical data given on this website is for preliminary information purposes only and is published without guarantee. All line drawings are for illustrative purposes only and should not be regarded as wholly accurate in every detail. We reserve the right to withdraw or to alter the specification of any product without notice. For more information, please consult our Terms of Business.

If you require any further information, our excellent customer service team is here to help so please call us on 01794 835835.



Grouped product items
CodeProduct NameList PriceYou SaveYou Pay Quantity
368860DP ABS VKR Metering Ball Valve EPDM Plain 1/2" £223.98 30% £156.79
368861DP ABS VKR Metering Ball Valve EPDM Plain 3/4" £266.25 30% £186.38
368862DP ABS VKR Metering Ball Valve EPDM Plain 1" £317.67 30% £222.37
368863DP ABS VKR Metering Ball Valve EPDM Plain 1 1/4" £407.38 30% £285.17
368864DP ABS VKR Metering Ball Valve EPDM Plain 1 1/2" £524.78 30% £367.35
368865DP ABS VKR Metering Ball Valve EPDM Plain 2" £667.73 30% £467.41
