Durapipe PPh Angle Seat Check Valve EPDM Plain
Useful Information
Key Features / Tech Specs & Dimensions:
- Manufacturer: Durapipe
- Seal material: ethylene propylene diene monomer rubber
- Size range from 20mm to 63mm
- Operating pressure rated to 10 bar
| Product Code | d (mm) | DN (mm) | A max (mm) | B (mm) | E (mm) | L (mm) | Z (mm) | H (mm) | Weight (g) |
| 384181 | 20 | 15 | 125 | 72 | 55 | 16 | 103 | 226 | 165 |
| 384182 | 25 | 20 | 145 | 84 | 66 | 19 | 120 | 388 | 227 |
| 384183 | 32 | 25 | 165 | 95 | 75 | 22 | 132 | 606 | 380 |
| 384186 | 63 | 50 | 240 | 139 | 120 | 38 | 222 | 2313 | 1555 |
Useful Info:
This Durapipe ball check valve has female plain and spigot connections, and allows maintenance to be carried out with the valve body still installed in line.
This valve is only suitable for use with liquids that have a specific gravity of less than 1.2g/cm³.
