Stainless Steel 90° Elbow
Useful Information
Key Features / Tech Specs:
- Material: stainless steel - CF8M (316)
- Conforms to ISO 4144 standard
- Operating temperature range of -20°C to 220°C
Technical Info:
| Nominal Diameter (inch) | A (mm) | Weight (kg) |
| ⅛ | 17 | 0.02 |
| ¼ | 19 | 0.026 |
| ⅜ | 23 | 0.044 |
| ½ | 27 | 0.07 |
| ¾ | 32 | 0.108 |
| 1 | 38 | 0.185 |
| 1¼ | 45 | 0.286 |
| 1½ | 48 | 0.397 |
| 2 | 57 | 0.518 |
| 2½ | 69 | 0.96 |
| 3 | 78 | 1.350 |
| 4 | 96 | 2.555 |
If you require any further information, our excellent customer service team is here to help so please call us on 01794 835835.
