PP Electro-Fusion End Cap

• Material (up to 225mm): Polypropylene Homopolymer (PP-H)
• Material (250mm and above): Polypropylene Random Copolymer (PP-R)
• Jointing method: Electrofusion / butt welding
• Function: Pipe end termination / sealing
• Application approval: Water use only
• Working pressure: 10 bar
• Standards: DIN 16962 Parts 5/6/7/8/9/12, ISO 7279:1984, ISO 15494:2003 Type B
• Operating temperature range: -20°C to 120°C

The PP Electro-Fusion End Cap is designed to permanently seal the end of polypropylene pipework, creating a robust and pressure-resistant termination point. Using electrofusion jointing technology, the end cap forms a homogeneous welded joint with the pipe, eliminating potential leak paths and providing long-term reliability.

Manufactured from polypropylene homopolymer (PP-H) up to 225mm and polypropylene random copolymer (PP-R) for larger diameters, the fitting maintains excellent mechanical strength across the full size range. The profiled body design helps distribute stresses evenly during fusion and in service, improving durability in demanding installations.

This electrofusion end cap is particularly well suited to systems where future disconnection is not required and a permanent, maintenance-free seal is preferred.

• Permanent electrofusion seal: Produces a strong, leak-tight pipe termination
• Optimised materials by size: PP-H up to 225mm, PP-R from 250mm upwards
• Profiled fitting body: Helps reduce stress concentrations at the joint
• Smooth internal finish: Prevents turbulence and dead zones at the pipe end
• Excellent chemical resistance: Suitable for aggressive and industrial fluids
• Low maintenance: Corrosion-resistant and ideal for buried or inaccessible pipework
