PP Socket

• Material: Polypropylene (PP-B)
• Manufacturing standard: BS 4991 : 1974
• Connection type: Plain socket (socket fusion)
• Working Pressure:

  • 1/2" - 4": 10 bar
  • 6": 6 bar
• Size range: 1/2" to 6"
• Application: Joining PPb pipe of equal diameter

The PP Socket is a plain polypropylene fitting designed to join two lengths of PPb pipe with the same outside diameter. Manufactured in accordance with BS 4991 : 1974, this fitting provides a simple, reliable and chemically resistant solution for creating straight pipe runs in industrial polypropylene pipework systems.

Designed for socket fusion welding, the PP socket creates a strong, homogenous joint once fused to the pipe, ensuring excellent integrity and long-term performance. Its smooth internal bore helps maintain consistent flow characteristics, minimising pressure loss through the joint.

Thanks to the inherent properties of polypropylene, these sockets are lightweight, corrosion-resistant and well suited to demanding chemical and process environments.

• Straight pipe connection: Joins two PPh pipes of the same diameter
• Socket fusion joint: Creates a secure, leak-tight welded connection
• Standards compliant: Manufactured to BS 4991 : 1974
• Excellent chemical resistance: Suitable for aggressive industrial fluids
• Smooth bore: Supports efficient flow with minimal turbulence
• Durable construction: Resistant to corrosion, scaling and rot
• Wide size range: Available from 1/2" up to 6"
• Lightweight design: Easy handling during installation
