D/C Pipe
Useful Information
Key Features / Tech Specs:
- Manufactured by Durapipe
- Material: PVC-U
- Dual containment
- Sizes: 1/2" x 2" to 4" x 8"
- Class E grey internal pipe
- Class C grey outer pipe
Useful Info:
| Product Code | Internal Pipe Diameter (inch) | Outer Pipe Diameter (inch) | Internal Pipe Thickness (mm) | Outer Pipe Thickness (mm) | Length (m) |
| 377562 | 1/2 | 2 | 1.9 | 3.4 | 6 |
| 377563 | 3/4 | 3 | 2.4 | 5 | 6 |
| 377564 | 1 | 3 | 3 | 5 | 6 |
| 377565 | 1 1/2 | 4 | 4.4 | 6.4 | 6 |
| 377566 | 2 | 4 | 5.4 | 6.4 | 6 |
| 377567 | 3 | 6 | 8.1 | 9.4 | 6 |
| 377568 | 4 | 8 | 10.3 | 12.2 | 6 |
These PVC-U pipes are dual contained for extra strength and support. The internal pipe is pressure rated up to 15 bar and is capable of operating at temperatures between 5°C and 60°C. The internal pipe is held in place via a centra-guide support located every 1.5 metres within the pipe keeping it in the correct position to ensure an accurate connection to the Centra-Lok™ fittings.
