MDPE Push Fit Wall Plate Elbow

• Type: Push Fit Wall Plate Elbow – 90°
• Connection Type:
• 1 x Push fit (MDPE pipe)
• 1 x Female BSP thread
• 1 x Wall mounting plate
• Material Composition:
• Body: UV-stabilised polypropylene
• Seal: Nitrile rubber (NBR)
• Mounting Plate: Integrated polypropylene base
• Pressure Rating: Up to 16 bar at 20°C
• Temperature Range: 0°C to +40°C (cold water systems)
• Standards Compliance: ISO 14236, Kiwa approved
• Pipe Compatibility: MDPE pipe (matching outer diameter)

Liner Requirement: Pipe liners (stiffeners) are strongly recommended

The MDPE Push Fit Wall Plate Elbow is designed to connect a length of MDPE pipe to a threaded fitting at a 90° angle, while also allowing for secure mounting to a flat surface. Commonly used for bib tap installations and external pipe terminations, this fitting is ideal for both domestic and commercial water systems. Manufactured from robust polypropylene and Kiwa approved for potable water use, it offers fast installation with long-lasting reliability. For optimal joint strength and sealing, the use of a pipe liner (stiffener) is strongly recommended.

• Wall-Mounted Connection: Allows for fixed, surface-mounted installation of taps or threaded fittings at 90°.
• Quick Push-Fit Assembly: Fast and tool-free installation with a secure compression seal.
• Durable Construction: Made from corrosion-resistant polypropylene suitable for external or internal use.
• High Pressure Capability: Rated up to 16 bar, making it ideal for potable water and irrigation systems.
• Kiwa Approved: Safe for use in drinking water applications and compliant with recognised quality standards.
• Supports Pipe Liners: Use of stiffeners is strongly advised to reinforce pipe ends and maintain a watertight seal.
