MDPE Electrofusion Elbow 180

• Type: Electrofusion Elbow – 180°
• Connection Type: Electrofusion socket x socket (equal diameter)
• Size Range: 25 - 40mm
• Material Composition: PE100 high-density polyethylene
• Pressure Rating: PN16 – 16 bar, gas - PE100 SDR 11
• Temperature Range: 0°C to +40°C (cold water systems)
• Terminal Pins: 4mm electrofusion terminals supplied
• Standards Compliance:
• BS EN 1555
• BS EN 12201
• WIS 4-32-14 & WIS 4-32-15
• Kiwa approved for drinking water systems
• Pipe Compatibility: MDPE pipe – same diameter

Installation Note: Use with compatible electrofusion welding equipment

The MDPE Electrofusion Elbow 180° is designed to join two MDPE pipes of the same diameter via electrofusion, forming a full U-turn in the pipeline. This fitting is ideal for installations where the pipeline must reverse direction while maintaining close parallel alignment, such as in compact or restricted spaces. Manufactured from robust PE100 polyethylene and Kiwa approved, it is suitable for potable water systems and delivers long-term, pressure-rated performance. Supplied with 4mm terminal pins, it is compatible with standard electrofusion welding units.

• 180° Directional Reversal: Allows the pipeline to turn back on itself with minimal space—ideal for compact layouts.
• Leak-Free Electrofusion Joint: Creates a permanent, pressure-resistant connection using standard electrofusion techniques.
• PE100 Construction: Provides high strength, durability, and resistance to corrosion and ground movement.
• Fully Certified for Water Use: Kiwa approved and compliant with all major UK water industry standards.
• Standard Terminal Pins: Supplied with 4mm pins compatible with common electrofusion control boxes.
