MDPE Electrofusion Coupling PN25

• Type: Electrofusion Coupling – PN25
• Connection Type: Electrofusion socket x socket (equal diameter)
• Size Range: 50 - 315mm
• Material Composition: PE100 high-density polyethylene
• Pressure Rating: PN25 – 25 bar, gas - PE100 SDR 7.4
• Temperature Range: 0°C to +40°C (cold water systems)
• Terminal Pins: 4mm electrofusion terminals supplied
• Standards Compliance:
• BS EN 1555
• BS EN 12201
• WIS 4-32-14 & WIS 4-32-15
• Kiwa approved
• Pipe Compatibility: MDPE pipe – same diameter

Installation Note: Use with compatible electrofusion welding units

The MDPE Electrofusion Coupling PN25 is designed to join two equal-diameter MDPE pipes via electrofusion, providing a high-integrity, leak-free connection suitable for high-pressure potable water systems. Manufactured from robust PE100 polyethylene and rated to PN25, this coupling offers enhanced pressure resistance for demanding installations. It is Kiwa approved for drinking water use and conforms to UK and European industry standards. Supplied with 4mm terminal pins, it is fully compatible with standard electrofusion welding equipment.

• High-Pressure Capability: PN25 pressure rating offers superior performance for demanding water systems.
• Permanent Electrofusion Joint: Creates a reliable, leak-free seal for long-term underground or exposed use.
• Durable PE100 Body: Provides excellent resistance to impact, stress, and environmental degradation.
• Compliant with Industry Standards: Certified for potable water applications and compliant with BS EN and WIS regulations.
• Kiwa Approved: Ensures safe use in regulated drinking water systems.
• Compatible with Standard Equipment: Supplied with 4mm pins for use with all common electrofusion control units.
