Adaptor Plain M x Thread F

Adaptor Plain M x Thread F

Click on the image to activate zoom.

All text and product images are the intellectual property and copyright of Pipestock Limited

Key Features / Tech Specs:

  • Material: Acrylonitrile Butadiene Styrene
  • WRAS approved product (approval number 1703070)
  • Spigot with male plain end and female threaded end
  • Threaded end is standard BSP

ABS-threaded-plain-adaptor-Diagram

Product Code Nominal Size (inch) L1 (mm) L2 (mm) Z (mm) E (mm)
352965 1/2 17 15 24 28
352966 3/4 20 16 27 34
352967 1 23 19 30 42
352968 1 1/4 27 21 36 51
352969 1 1/2 32 21 41 58
352970 2 39 25 48 72



Useful Info:

  • M = Male
  • F = Female

Used to join together two pieces of ABS pipe of the same dimensions. ABS solvent cement should be used along with cleaner to glue the plain end and the pipe together.

Please note, the WRAS approval for this fitting only covers use above ground and a maximum operating pressure of 15 bar.



If you require any further information then don’t hesitate to ring us here at Pipestock on 0845 634 1053. We’re always happy to help!

More Info Close
Code
Product Name
List Price
You Pay
You Save
Quantity
ABS Adaptor Male Spigot Plain x Threaded Female 1/2"
Code
352965
Product Name
ABS Adaptor Male Spigot Plain x Threaded Female 1/2"
List Price
£4.84
You Pay
£1.16
You Save
76%
Qty
ABS Adaptor Male Spigot Plain x Threaded Female 3/4"
Code
352966
Product Name
ABS Adaptor Male Spigot Plain x Threaded Female 3/4"
List Price
£6.17
You Pay
£1.48
You Save
76%
Qty
ABS Adaptor Male Spigot Plain x Threaded Female 1"
Code
352967
Product Name
ABS Adaptor Male Spigot Plain x Threaded Female 1"
List Price
£8.56
You Pay
£2.05
You Save
76%
Qty
ABS Adaptor Male Spigot Plain x Threaded Female 1 1/4"
Code
352968
Product Name
ABS Adaptor Male Spigot Plain x Threaded Female 1 1/4"
List Price
£10.85
You Pay
£2.60
You Save
76%
Qty
ABS Adaptor Male Spigot Plain x Threaded Female 1 1/2"
Code
352969
Product Name
ABS Adaptor Male Spigot Plain x Threaded Female 1 1/2"
List Price
£14.75
You Pay
£3.54
You Save
76%
Qty
ABS Adaptor Male Spigot Plain x Threaded Female 2"
Code
352970
Product Name
ABS Adaptor Male Spigot Plain x Threaded Female 2"
List Price
£20.61
You Pay
£4.95
You Save
76%
Qty
6 products
